Specifications
- Length x width x height 1.020 x 400 x 885 mm
- Lowest working height 680 mm
- Size of base plate (L x W) 590 x 400 mm
- Operating weight 74 kg 163 lb
- Shipping weight (including packaging) 77 kg
- Shipping size 675 x 535 x 800 mm
- Compaction depth (depending on soil) up to 30 cm
- Compacted area (soil) up to 550 m2/h
- Forward speed (soil) up to 23 m/min
- Gradeability up to 30 %
- Vibration frequency 97 Hz 5,800 Hz
- Max. centrifugal force 13 kN 2,925 lb
- Engine Type air-cooled, 4 cycle single cylinder, gasoline engine Honda
- Fuel tank capacity 3,7 l
- Fuel consumption 1,8 l/h
- Special contoured running surfaces and rounded edges provide maximum performance and manoeuvrability
- Completely enclosed belt protected by a lightweight beltguard for reduced wear and minimal service.
- Newly designed “low-vibration” guide handle greatly improves operator comfort and minimizes operator fatigue.
- Heavy-duty shockmounts on engine console dampen vibrations thereby reducing wear on the components.
- Exciter bearing design requires minimal maintenance for improved productivity.
- Ergonomically designed lifting handles offer easier loading and unloading for operator during transport.
