Manufactured to meet latest safety regulations. Heavy cast iron base with swivel head giving cutting angles of 45°-0-45°. Heavy-duty induction motor with two-stage safety switching and no-volt release circuitry prevents inadvertent re-start after power interruption. Fitted with 24Volt safety switching circuit to reduce risk of electric shock. Coolant system, vice and bar stop included. Designed for cutting ferrous metals. Supplied without blade. An optional stand is available under Model No. SM2504ST.
Specifications
- Model No: SM2504
- Blade Ø: 250mm
- Motor Power: 970W
- Supply: 230V 1ph
- Blade Speed: 42rpm
- Vice Capacity: 100mm
- Weight: 85kg
- Cutting Capacities (mm): SM2504
- Rod 90°/45°: 40/35
- Pipe 90°/45°: 75/65
- Sq. Tube 90°/45°: 65/58
- Rect. Tube 90°/45°: 90 x 50/70 x 50
