Fan cooled DC power supply for TIG and arc welding applications. Suitable for welding steels, deoxidised copper, nickel and titanium.
TIG cycle includes current down-slope regulation.
Features HF or lift striking.
Includes remote control connector for foot pedal or hand controller.
Supplied with shoulder strap.
Optional Arc Accessory Kit Model No: INV/16
Specifications
- Model No: TIG130HF
- Power Output: 5-130A
- Duty Cycle: 60% @ 73A
- Electrode Capacity: Ø1.6-3.2mm
- Power Absorbed: 3.7kW
- Mains Voltage: 230V - 1ph
- Insulation Class: H
- Protection: IP21
- Weight: 5.3kg
- TIG Accessories Included: Yes
- Arc Accessory Ref (Optional): INV/16
- Foot Pedal Ref (Optional): INV/TIG/5
- Current Control Ref (Optional): INV/TIG/7
