Wacker PS2 400 Submersible Pump

Lightweight, portable, single phase submersible pumps are designed to handle clean and dirty water and small solids. Built for the demands of construction, mining, municipality and farm applications.

Benefits

• Lightweight, compact design for easy transport and positioning of pump.
• Built-in thermal protection prevents motor damage due to impeller blockage, reducing service repairs.
• Heavy-duty power cord with strain relief resists pullout and abrasion reducing costly repairs.
• Insulation on all conductors of the power cable are protected by a water block system to prevent wicking of water into the motor.
• Silicon carbide faced double mechanical seals run in an isolated oil-filled cavity, allowing for seal lubrication, cooling and overall motor protection.
• Preliminary v-ring or lip seal (depending on model) shields the mechanical seal from abrasive wear due to suspended debris in pumping fluid.
• Semi-vortex impeller allows for optimum wear resistence.

Specifications

• Discharge diameter 50 mm
• Length x width x height 250mm x 185mm x 330mm
• Operating weight 11.3 kg
• Max. head 12 m
• Max. discharge 200 l/min
• Max. pressure 1.15 bar
• Solid size capacity 9.5 mm
• Motor type 400 watt Single phase/50 Hz 110 volt
• Cable length 6 m
• Impeller semi-vortex Urethane rubber
