Benefits
- Aluminium alloy body with heavy-duty pump diaphragm provides a lightweight, reduced maintenance package that ensures long life
- Surge chamber on inlet sides results in smooth pumping operation by absorbing pressure spikes while reducing wear
- Oil bath lubricated transmission ensures continuous lubrication to all parts of the gear transmission system, reducing both maintenance costs and lost production time
- Hardened forged gears extend pump life and provide efficient power transmission from the engine to the pump
- Straight through water flow design provides high production pump capacity and less down time blockages
- Discharge & suction diameter 50 mm
- Length x width x height 1015mm x 455mm x 585mm
- Operating weight 52 kg
- Max. head 7.5 m
- Max. discharge 189 l/min
- Max. suction lift 7.5m
- Solid size capacity 32 mm
- Honda 4hp petrol engine
- Fuel tank capacity 2.5 litres
- Fuel consumption 1.1 l/h
