SkyJack 9233RT Rough Terrain Diesel Scissor Lift

£46224.00
SkyJack 9233RT Rough Terrain Diesel Scissor Lift Product code: SKJ1010 £46224.00  Inc. VAT and mainland UK delivery
Ask a Question
Enter your details and we will get back to you

Product Information

SkyJack logo

SkyJack 9233RT Rough Terrain Scissor Lift working height 11.89 metres

Consistent with Skyjack’s robust and reliable design features, the SJ 8841 offers an easy to service, low maintenance design to meet the demands of the most challenging job site environments.
Offering a huge platform and heavy duty capacity, the SJ 8841 features a fuel efficient GM 1.6L Vortec dual fuel engine powering Skyjack’s robust axle based 4WD system resulting in 30% gradeability.

Please note that carriage is NOT included in the price of this machine. For a quote please call 01202 233202 or email:[email protected]

Features

  • ■ AXLDRIVETM Axle-based 4WD system
  • Operator controlled locking rear differential and limited slip
  • front differential
  • SKYCODEDTM Color coded and numbered wiring system with
  • on-board interface
  • Drivable at full height (except SJ9253 RT – 33’)
  • Diesel engine
  • High strength and impact resistant composite control box
  • Fully proportional drive and lift functions
  • Up to 2,750 lbs (1,247 kg) capacity
  • Self-centering scissor design to support dual extension decks
  • Oversized platform with minimal clearance over side of machine
  • 5’ (1.52 m) Roll-out extension deck
  • Wet disc SAHR brakes (rear axle)
  • Auto leveling outriggers (standard only on SJ9253 RT)
  • Up to 40% Gradeability
  • 110V AC outlet on platform with GFI
  • Tilt alarm with drive & lift cut-out
  • All motion audible alarm
  • Lanyard attachment points
  • Tie down/lifting lugs
  • Overload sensing system
  • DC Powered emergency lowering
  • Operator horn
  • Flashing Light
  • Fold down hinged railing system
  • Full height spring hinged gate
  • Grip lug, solid tires
  • Telematics ready
  • 2 Year Gold Leaf Warranty (5 year structural warranty)

Specifications

  • Working height 14.5 metres
  • Platform height 12.5 metres
  • Lowered platform height 1.8 metres
  • Width 2200mm x length 3500mm x 2900mm height (railings up), 2200mm (railings down)
  • 30% gradeability
  • Cage capacity 681kg
  • 5 persons maximum
  • Platform size 1700mm x 3400mm - extended 5700mm
  • Extension deck roll out 2 x 1200mm
  • Travel speed lowered 4.5km/hour
  • Travel speed raised 0.34km/hour
  • Turning radius inside 2900mm
  • Turning radius outside 6300mm
  • Lift time 56 seconds
  • Weight 6173kg
