SkyJack SJ111 3220 Scissor Lift Access Platform

£11211.00
SkyJack SJ111 3220 Scissor Lift Access Platform Product code: SKJ1006 £11211.00  Inc. VAT and mainland UK delivery
Ask a Question
Enter your details and we will get back to you

Product Information

SkyJack logo

SkyJack SJ111 3220 Scissor Lift working height 8.1 metres

The Narrow Conventional Series DC Electric Scissor Lifts offer high capacity and large platform areas, making them suitable for any on-slab application. Featuring variable speed rear wheel hydraulic drive, the SJIII 3220 and SJIII 3226 offer working heights up to 9,9 m and 30% gradeability.The lightest machines in their class, these models offer a standard 0,9 m roll out extension deck, and both models can be driven at full height.

The SJIII 3220,boasting an industry leading 408 kg capacity, can also access through standard doorways. Consistent with Skyjack’s robust and reliable design features, the Narrow Conventional Series DC Electric Scissor Lifts utilize Skyjack’s standard colour coded and numbered wiring system with analog based controls.

Features
  • Driveable at full height
  • Universal battery charger
  • Colour coded and numbered wiring system
  • Swing out trays for easy access
  • Joystick proportional control for drive/lift
  • Tilt alarm with drive/lift cut out
  • Wiring for AC outlet
  • Lanyard attachment points
  • Lowering warning system
  • Overload sensing system
  • Forklift pockets, tie downs, lifting lugs
  • Operator horn
  • 24 volt battery power
  • Base controls
  • Spring loaded half height gate
  • Warranty - 2 year parts and labour and 5 year structural
Specifications
  • Working height 8.1 metres
  • Platform height 6.1 metres
  • Lowered platform height 1.0 metres
  • Width 800mm x length 2300mm x 2100mm height (railings up), 1700mm (railings down)
  • 30% gradeability
  • Cage capacity 408kg
  • 2 persons maximum
  • Platform size 700mm x 2100mm
  • Extension deck roll out 900mm
  • Travel speed lowered 3.1km/hour
  • Travel speed raised 1.1km/hour
  • Turning radius inside 1300mm
  • Turning radius outside 2800mm
  • Lift time 22 seconds
  • Weight 1594kg
