Altrad-Belle BGA Pump System

Altrad-Belle BGA Pump System Product code: BEL1053 £491.54  Inc. VAT and mainland UK delivery
Ask a Question
Enter your details and we will get back to you

Product Information

Altrad Belle Logo

A heavy duty poker drive unit powered pump. Robust and capable of pumping even the dirtiest of water. This Pump needs one of the 3 Drive Unit Options. Honda GX120, Honda GX160 or Hatz Diesel.

  • Pump with high output and a capacity of 25m3/hour
  • Cast steel impeller
  • Solid size capacity : 15mm
  • High quality components and strong flexible shaft 5m
  • Easy to use : Priming not necessary
  • Two-dog coupling identical to BGA poker vibrators which enable compatibility and versatility in utilisation between water removal and concreting work
  • Autonomous, portable and light weight in size, this pump can be used in a multitude of applications
  • Same engine power units used together with BGA poker vibrators
  • Discharge hose of 10 meter and 75mm, firemans quick release coupling options available
  • 2800 rpm, max. head height 13
  • Specifications
  • Maximum flow rate 25,000 litres per hour
  • Speed ratings: 2800 - 3600 rpm
  • Shaft length 5 metres
  • Outlet size 75mm
  • Pump weight 6kg
  • Total weight 19.5kg

Operators manual
