Product Information
Single direction vibratory plate BPS1030A for soil
Excellent driving features: No matter whether used on asphalt or soil – the BPS is easy to manoeuvre and provides perfect surfaces.
Clean finish to the kerb is easily generated due to the square side-profile of the base plate.
The control handle addresses the steering movements clearly, yet nevertheless generates low hand-arm vibrations of less than 5 m/s², which enable long, comfortable working conditions.
Easy to transport: A large lifting eye and wide, ergonomically designed carrying handles make moving and loading the machine both easy and comfortable.
Maintenance-free: The BPS series is equipped with an extremely sturdy fan belt and has storage with lifetime lubrication. As a result, it is practically maintenance-free.
Accessories are available separately: Wheel set and paving stone sliding mechanism round off the application areas of the APS.
Normal delivery 2-3 working days
Specifications
- Part No. 5100065701
- Operating height 663mm
- Size of base plate (L x W) 320mm x 496mm
- Operating weight 53kg
- Compacted area (soil) 500m2/h
- Forward speed (soil) 26m/min
- Vibration frequency 98Hz
- Max. centrifugal force 10kN
- Fuel tank capacity 2.5Litres
- Fuel consumption 0.33 l/h
- Power transmission from drive motor via automatic centrifugal belt drive direct to exciter.
