Sealey PH20 1.8ton Folding Engine Crane

• 1.8tonne Folding crane - economy model.
• Folds for easy storage, freeing valuable workshop space when not in use.
• Heavy-duty castors.
• Weighs only 83kg and is perfect for mobile or workshop use.
• Pump access from side.
• Delivered in knock-down form for reduced freight cost.
• Some self-assembly required.

Specifications

• Make: Sealey
• Model No: PH20
• Lifting Cap in Position 1: 1800kg
• Lifting Cap in Position 2: 1350kg
• Lifting Cap in Position 3: 900kg
• Lifting Cap in Position 4: 450kg
• Maximum Lift Height at Minimum Jib Extension: 1880mm
• Maximum Lift Height at Maximum Jib Extension: 2320mm
• Length of Jib Position 1: 1020mm
• Length of Jib Position 2: 1200mm
• Length of Jib Position 3: 1380mm
• Length of Jib Position 4: 1560mm
• Height of Frame: 190mm
• Length of Frame: 1740mm
• Overall Height: 1560mm
• Maximum Width of Frame: 1040mm
• Width Inside Frame: 890mm
• Distance between Centres of Rear Wheels: 750mm
• Weight: 83kg
• For Warranty see: Sealey Warranties
• Standard delivery: 1-2 days
• This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
