The ELITE‑DRILL D1610 is engineered for wet drilling in hard and high-density concrete. With a 400 mm diameter and 500 mm core length, it belongs to Husqvarna's Gold-level performance range. It is ideally suited for use with core drill motors such as the DM 1 PACE, DM 430, and DM 400, delivering excellent drilling speed and longevity.
This core bit is built with 19 laser-welded Z-segments incorporating a rooftop design and chamfered inner edges for enhanced penetration, core removal, and reduced vibration. Its steel core and 11/4″-7 UNC (CR128) threaded connection ensure robust performance and secure compatibility with high-power core drills.
| Specification | Details |
|---|---|
| Part Number | 547564701 |
| Diameter | 400 mm |
| Core Length | 500 mm |
| Connection | CR128 / 11/4″‑7 UNC |
| Coolant | Wet only |
| Power Range | 3.5-5.5 hp (2.5-4 kW) |
| Segment Count | 19 |
| Segment Width | 4 mm |
| Segment Height | 11 mm |
| Performance Level | Gold |
Users benefit from a fast, controlled drilling experience with minimal vibration and efficient material removal. The D1610 is especially valued in heavy-duty applications such as construction and utility installation where accuracy and endurance are critical. It delivers consistently clean cores and high productivity with reduced operator fatigue.
Q: Can I use this bit dry?
A: No, this core bit is designed specifically for wet drilling and should always be used with adequate water cooling.
Q: Is it compatible with the Husqvarna DM 1 PACE?
A: Yes, this bit is optimised for use with the DM 1 PACE and is fully compatible with Husqvarna drills using a CR128 connection.
Q: Are other sizes available in the D1610 series?
A: Yes, the D1610 series includes a wide range of diameters from 52 mm to 350 mm. The 400 mm variant is available for large-diameter applications.
