Specifications
- Length x width x height 675 x 345 x 965 mm
- Shoe size (w x l) 280 x 330 mm
- Operating weight 66 kg
- Shipping weight (including packaging) 71 kg
- Shipping size 710 x 420 x 990 mm
- Compaction depth (depending on soil) 58 cm
- Stroke 72 mm
- Impact energy 85 J
- Force/blow per CIMA - LEMB 13,4 kN 3,025 lb
- Percussion rate up to 700 1/min
- Travel speed up to 17,4 m/min
- Compacted area 291 m2/h
- Engine Type air-cooled, 2-stroke, single cylinder WACKER WM 80 petrol engine
- Horsepower 3 kW 4 hp
- Fuel to oil ratio 120:1
- Fuel consumption 1,2 l/h
- Fuel tank capacity 3,0 l
- Oil tank capacity 0,70 l
- Powered by WACKER's exclusive WM 80 engine, the only 2-cycle engine specifically designed and built for vibratory rammers and meets EPA and European air emission standards.
- Patent-pending vented carburetor evacuates air from the fuel line for easy starting. An integrated fuel valve and gas lever also provide for simple operation and easy starting by eliminating air in the fuel line.
- A unique three-stage air filtration system provides a virtually dust-free engine for longer life and improved durability. A filter minder tells the operator when the air filter needs to be changed.
- The guide handle offers a highly engineered, built-in shockmount system to reduce HAV (hand-arm vibration) and improve operator comfort.
- Automatic shutoff feature will shut down the unit if left idling for an extended period of time, reducing emissions and carbon build-up.
- Rugged rammers designed for the compaction of cohesive, mixed and granular soils in confined areas.
